Technical Specification | Unit | SAW153 | SAW154 |
Min. sawing length | mm | 230 | 260 |
Sawing thickness | mm | 10-85 | 10-125 |
Throat depth | mm | 460 | 610 |
Saw blade diameter | mm | Ø250-305 | Ø305-405 |
Spindle diameter | mm | Ø25.4 | Ø25.4 |
Saw spindle speed | r/min | 4000 | 3500 |
Main motor power | kW | 7.5 | 11 |
Feeding motor power | kW | 1.5 | 2.2 |
Feeding speed | m/min | 12.5/16/19.5/24 | 6~25 |
Fixed table size | mm | 1100×1600 | 1230×1750 |
Overall dimensions | mm | 1800×1100×1356 | 2100×1400×1500 |
Net.weight | kg | 980 | 1200 |
