MODEL | SAW3200TYA | SAW2800TYA | SAW3800TYA |
Dimension of sliding table | 3200×375mm | 2800×375mm | 3800×375mm |
Max cutting length | 3200mm | 2800mm | 3800mm |
Max cutting width | 1250mm | 1250mm | 1250mm |
Cutter blade specification | φ250-φ300mm | φ250-φ300mm | φ250-φ300mm |
Max.working height | 80-120mm | 80-120mm | 80-120mm |
Diameter of guide shaft spindle | 40mm | 40mm | 40mm |
45°max working height | 55-90mm | 55-90mm | 55-90mm |
Speed of main saw spindle | 4000/6000rpm | 4000/6000rpm | 4000/6000rpm |
Main spindle diameter | 30mm | 30mm | 30mm |
Tilting saw bladle | 0-45° | 0-45° | 0-45° |
Main motor power | 4KW（OPTIONAL 5.5kw） | 4KW（OPTIONAL 5.5kw） | 4KW（OPTIONAL 5.5kw） |
scoring saw size | ∮120mm | ∮120mm | ∮120mm |
Non-loadspeed | 8000r.p.m | 8000r.p.m | 8000r.p.m |
Scoring spindle diameter | 20mm | 20mm | 20mm |
Scoring motor power | 0.75kw | 0.75kw | 0.75kw |
Net weight | 680kg | 650kg | 750kg |
Gross weight | 780kg | 750kg | 880kg |
Overall dimensions | 3250×3150×900mm | 2850×3150×900mm | 3850×3150×900mm |
